Dimension Table
Dimensions for PTFE Coated Stainless Steel Slotted Hexagon Head Bolt in all available sizes are shown according to the product drawing above.
Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom right of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080
Material: PTFE Coated
Measurement System: Metric
Drive Type: Hexagon (External)
Blue
260°C
UL94 V0
PTFE Coated Stainless Steel Slotted Hexagon Head Bolt conform to the following Standards/Norms:
ISO 4017
DIN 933
CSN 021103
PN 82105
UNI 5739
PTFE Coated Stainless Steel Slotted Cheese Head Screws, available in sizes ranging from M5 to M20 with lengths between 10mm and 180mm. These high-quality screws feature a cylindrical head with a flat top and a single slot, allowing for easy tightening and loosening with a flat-blade screwdriver. Crafted from premium stainless steel and coated with PTFE (Polytetrafluoroethylene), they offer exceptional corrosion resistance, low friction, and enhanced durability. The PTFE coating provides a non-stick surface and excellent chemical resistance, making these screws ideal for applications in harsh environments, woodworking, furniture assembly, and general construction, where reliable and long-lasting fastening solutions are essential.
Metric Size – M5, M6, M8, M10, M12, M14, M16, M20
Length (mm) – 10, 12, 16, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 180
PTFE (Polytetrafluoroethylene) coated stainless steel combines the desirable properties of both materials to create a versatile and highly functional composite. Here's a brief overview of its properties:
What are Slotted Hexagon Head Bolts?
Slotted hexagon head bolts are fasteners with a hexagonal head and a single slot (or "cheese") across the head's diameter. This slot allows for tightening or loosening using a flat-blade screwdriver or a slotted screwdriver. These bolts are commonly used in applications where frequent adjustments or removals are required, such as in machinery, automotive assembly, and construction. The hexagonal head provides a secure grip for tightening with a wrench or spanner, while the slot allows for easy accessibility and adjustment with common hand tools.
The PTFE Coated data sheet is available as a PDF to download below.
Return components within 90 days for a full refund. Please see returns terms and conditions for further information.
Size | Head Height (mm) | Across Flats (mm) |
M5 | 3.5 | 8 |
M6 | 4 | 10 |
M8 | 5.3 | 13 |
M10 | 6.4 | 15 |
M12 | 7.5 | 16 |
M14 | 8.7 | 18 |
M16 | 10 | 21 |
M20 | 12.5 | 30 |
Dimensions for PTFE Coated Stainless Steel Slotted Hexagon Head Bolt in all available sizes are shown according to the product drawing above.
